Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 5730 | MH-5730QRC | Red | 1.8 | 2.4 | 15 | 20 | 620 | 630 | 150 | 120 |
| 5730 | MH-5730QYC | Yellow | 1.8 | 2.4 | 10 | 15 | 585 | 595 | 150 | 120 |
| 5730 | MH-5730QOC | Orange | 1.8 | 2.4 | 300 | 20 | 25 | 610 | 150 | 120 |
| 5730 | MH-5730QBC | Blue | 2.8 | 3.4 | 8 | 12 | 460 | 470 | 150 | 120 |
| 5730 | MH-5730IBC | Ice blue | 2.8 | 3.4 | 45 | 50 | X:0.19 Y0.28 | 150 | 120 | |
| 5730 | MH-5730QGC | Pure Green | 2.8 | 3.4 | 20 | 30 | 520 | 530 | 150 | 120 |
| 5730 | MH-5730QPC | Purple | 3.0 | 3.4 | 7 | 10 | 390 | 400 | 150 | 120 |
| 5730 | MH-5730WWC | Warm white | 2.8 | 3.4 | 50 | 55 | 2000 | 3000 | 150 | 120 |
| 5730 | MH-5730NWC | Natural white | 2.8 | 3.4 | 50 | 55 | 5000 | 6500 | 150 | 120 |
| 5730 | MH-5730CWC | Cool white | 2.8 | 3.4 | 50 | 60 | 8000 | 20000 | 150 | 120 |
